Weight Capacity

21 Stone 6lbs (136 kg)

Maximum Speed

4 mph (6 km/h)

Ground Clearance

5.7 cm (2.25")

Overall Length

100.3 cm (39.5")

Overall Width

49.5 cm (19.5")

Turning Radius

112 cm (44.125")

Standard Controls

LED Display

Heaviest Piece (when disassembled)

16 kg (35 lbs) Front Section

Total Weight (without batteries)

36 kg (79.5 lbs)

Seating

Foldable, compact, vinyl-covered molded plastic

Tyres

Rear: 6.35 cm x 20 cm (2.5” x 8”) solid 4- Wheel: Front: 5cm x 17.78 cm (2” x 7”) solid Rear: 6.35 cm x 20 cm (2.5” x 8”) solid

Suspension

None

Battery Requirements

Two 12-volt, deep cycle (standard) Size: 2x 12 AH | Optional: 18AH

Battery Weight (each)

12 AH: 8.8 kg (19.5 lbs.) battery pack 18 AH: 13.4 kg (29.5 lbs.) battery pack

Note

1. Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or - 3 %. 2. Specification varies with user weight, terrain, battery type, battery condition and tire pressure. 3. Battery weight may vary based on manufacturer. Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%. The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice.
